UROVO I6310-T ANDROID 7.1 DUAL SIM SMART PDA (EOL)

i6310T-UROVO
i6310T-UROVO-water
i6310T-UROVO-Side

UROVO I6310-T ANDROID 7.1 DUAL SIM SMART PDA (EOL)

Urovo enterprise mobile computer i9310-T is slim like a smartphone but with a professional barcode engine. It offers fast capture of 1D/2D barcodes, greatly improving the efficiency of industrial business management. With its global 4G network, the i9310-T helps to connect the world.

5″ HD / 4G / Safedroid OS / 1D or 2D barcode scanner IP65 / 1.5m drop test.

i6310T-UROVO

UROVO I6310T DATASHEET
UROVO I6310T REFERENCE GUIDE

Description

FEATURED

End of life (EOL) – See related product replacements below

Urovo’s Enterprise security intelligent terminal i6310- T is an enterprise smartphone. It comes with state of the art features such as an advanced capacitive screen, seamless voice and data connectivity, powerful data collection capabilities and highly optimized power design.

Summary

Advanced capacitive screen

5” HD (720 x 1280)
Industrial grade sensitivity, works with gloves and wet fingers

Powerful data collection

Optional 1D or 2D scan engine
13.0 MP rear camera and 8MP front camera

Seamless voice and data connectivity

7 band WAN radio with high speed data access
Background noise cancelling technology for smooth and clear voice conversation
802.11b/g/n WiFi

Elegant design with maximum industrial reliability

Stylish, modern look and feel
IP65 rating
Internal structure built with magnesium alloy for maximum durability

Enterprise security

Custom OS with various security enhancements that change Android from a consumer OS to an industrial platform
Enterprise features include secure OS, device management, real-time data access
Supports PSAM slot, meeting the requirement of financial institutions and government agencies

Highly optimized power design

3.8V, 4000 mAh battery with low power electronics ensures long operation hours
POGO PIN design for quick and non-intrusive charging can further prolong device life span and durability.



Urovo-i6300-T_Dimension Measuring Sensor Urovo-i6310-T_Pistol Grip Urovo-i6310-T_thinnest scanner

SUITABLE APPLICATIONS

  • Inventory Counting,
  • Access Control,
  • Back Office Inventory Management
  • Hospitality
  • Restaurants
  • Stock Management
  • Food Traceability

Specifications

Physical Characteristics

  • Dimensions:
    152 mm x 78 mm x 15 mm
  • Weight:
    283g
  • Buttons:
    Side SCAN button x 2, user-defined function button, The volume switch button, ON / OFF button
    Input Chinese/ English, and supports handwriting and soft keyboard

Basic Characteristics

  • O.S.
    Safendroid OS (Based on Android 7.1)
  • CPU:
    Octa-Core 1.4GHz
  • Display:
    5.0 inch TFT-LCD HD (720 x 1280) color screen
  • RAM:
    4GB
  • ROM 64GB/8GB
  • Dimensions:
    154mm x 76.2 mm x 12.6mm
  • Weight:
    210g (Battery included)
  • Buttons:
    Volume up/down, Power button, Custom buttons x3
    Input Chinese / English, and supports handwriting and soft keyboard

Barcode Scanner

  • 1D Laser Code:
    39; Codabar; Code 128; Discrete 2 of 5; IATA 2 of 5; Interleaved 2 of 5; Code 93; UPC A; UPC E0; EAN 8; EAN 13; MSI; EAN 128; UPC E1; Trioptic Code 39; Bookland EAN; Coupon Code; RSS-Limited; RSS-14; RSS-Expanded.
    2D CMOS
  • 1D Symbologies:
    UPC/EAN, Bookland EAN, UCC Coupon Code, ESSN EAN, CODE 39, CODE 128, GS1-128, ISBT 128, Trioptic Code 39, CODABAR, MSI, Interleaved 2/5, Discrete 2/5, Chinese2/5 , Korean3/5, Matrix 2/5, CODE 32,CODE 93, CODE 11, Inverse 1D, GS1 DataBar, Composite Codes
  • 2D Symbologies:
    PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, MaxiCode, QR Code, Aztec, Aztec Inverse
  • Postal Codes:
    U.S. Postne, U.S. Planet; U.K. Postal; Japan Postal; Australian Postal; Netherlands KIX Code; USPS 4CB/One Code/Intelligent Mail; UPU FICS Postal

Power

  • Main Battery:
    Rechargeable 3.8V, 4000mAh lithium polymer battery pack (Typical Operation time ≥8 hours）
  • RTC Battery:
    Real time clock battery

Radio Communication

  • Wi-Fi:
    802.11 b/g/n wireless communication
  • Bluetooth:
    Bluetooth 4.1 + BR/EDR+BLE
  • 4G:
    FDD-LTE(B1,B2,B4,B7,B8,B20,B28A,B28B)
  • 3G:
    UMTS(HSDPA / HSPA+(850,1900,2100MHz)
  • 2G:
    GSM/EDGE/GPRS: 900/1800MHz

Payment

  • Magcard Supports ISO7811/7812/7813, and supports triple track (tracks 1/2/3), bi-directional
  • Chip Card Supports ISO7816 standard
  • Contactless Cards(RFID):
    Supports 14443A / 14443B
    Supports 10MHz~20MHz frequency, and reading time less than 300 milliseconds
  • Printer:
    58mm printing paper, 203dpi / 8dot / mm;
  • Printing speed:
    50~70mm/s, and supports barcode printing
    30mm paper roll
  • Product Certification:
    CCC, CE, PBOC3.0 Level 1&2, EMV4.3 Level1&2

Expansion and peripherals

  • Camera:
    13MP/8MP rear camera with LED flash and auto-focus function, 5NP/2MP front camera
  • GPS:
    GPS, Supports A-GPS, GNSS, Bei-Dou satellite navigation system.
  • Slot Micro SD/TF x 1(a maximum of 32 GB), SIM x 2
  • PSAM Conforms to ISO7816 standard x 2
  • Interfaces:
    Mini USB x 1, POGO PIN x 1, 3.5mm Audio Jack x 1, DC Jack
  • Audio Frequency:
    Loadspeaker,Microphone, Earpiece

Accessories

  • Standard:
    Power adaptor, Data line, One battery.
  • Optional:
    Cradle, Carrying Pouch, Wrist Strap, Stylus, Paper roll.

User Environment

  • Operating Temperature:
    -10℃ ~ 50℃
  • Storage Temperature:
    -20℃ ~ 70℃
  • Humidity:
    5% ~ 95% (non-condensing)
  • Drop Durability:
    1.2m
  • IP:
    65

Warranty

12 months Warranty
