Specifications

WIRELESS COMMUNICATIONS

• Local area network (WLAN):
  IEEE 802.11 a/b/g/n/ac and 802.11 d/h/i/k/r/v/w;
  Wi-Fi alliance Certification; WPA3 (Personal and Enterprise)
• Personal area network (WPAN):
  Class 2, Bluetooth® V5.0, Low Energy (BLE) Support
• Ncf Communication:
  Support for the following standards: ISO14443-4 (type-A,
  type-B); ISO15693; Mifare; Felica
• WWAN Cellular:
  LTE-Advanced / 4G+; Cat 6
  • EMEA and ROW Configuration: GSM: Quad band;
  WCDMA: B1/5/8; FDD_LTE: B1/3/5/7/8/20/28; TDD_LTE:
  B38/39/40/41
  • North America Configuration (PTCRB certified):
  GSM: Quad band; WCDMA: B1/2/4/5/8; FDD_LTE:
  B2/4/5/7/12/13/17/25/26/28
• Global Positioning System (GPS):
  Integrated Assisted-GPS (A-GPS)
  Supported Types: GPS, GLONASS, BeiDou

DECODING CAPABILITY

• 1D/Linear codes:
  Auto discriminates all standard 1D codes including GS1
  DataBar™ linear codes.
• Digital Watermark Codes:
  Digimarc® Barcode
• 2D codes
  Aztec Code, Data Matrix, HanXin Code, MaxiCode,
  MicroQR Code, QR Code, Dotcode
• Postal codes:
  Australian Post, Japan Post, KIX Code, PLANET,
  POSTNET, Royal Mail Code (RM4SCC), USPS Intelligent
  Mail
• Stacked Codes:
  Micro-PDF417, PDF417, GS1 Composite, GS1 DataBar
  Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar
  Stacked Omnidirectional, OCR (ID Cards, Passport)

ELECTRICAL

• Battery:
  Replaceable battery pack with rechargeable
  Li-Ion batteries; 3.8 V; 4,100 mAh (15.6 Watt-hours)
• Wireless charging:
  10 Watt fast charging

ENVIRONMENT

• Drop resistance:
  Withstands drops from 1.5 m / 5.0 ft onto concrete (with rubber boot); Withstands drops from 1.2 m / 4.0 ft onto concrete (without rubber boot). Tested onto steel/ concrete according to IEC 68-2-32 Method 2 and MIL STD
  810G Transit drop test.
• Temperature:
  Operating: -20 to 50 ºC / -4 to 122 ºF
  Storage/Transport: -30 to 70 ºC / -22 to 158 ºF
• Tumbles:
  Withstands 1000 hits from 0.5 m / 1.6 ft and 250 hits from 1.0 m / 3.2 ft per IEC 600-2-32 with rubber boot;
  Withstands 600 hits from 0.5 m / 1.6 ft per IEC 600-2-32 without rubber boot
• Particulate and water sealing chemical resistance:
  IP65
• Health cleanable:
  Isopropyl Alcohol, Hydrogen Peroxide, Clorox® Bleach;
  applicable for both the device and docks

INTERFACES

• Interfaces:
  USB-C: High Speed USB 2.0 Host and Client

SENSORS

• Accelerometer:
  3-Axis accelerometer to detect orientation
• Magnetometer:
  Senses orientation (eCompass)
• Gyroscope:
  Senses angular velocity on WWAN models only
• Vibration:
  Software programmable for duration and intensity
• Ambient Light:
  Auto adjusts display backlight
• Proximity:
  Auto deactivates display when close to face

PHYSICAL CHARACTERISTICS

• Dimensions:
  15.5 x 7.8 x 1.87 cm / 6.1 x 3.07 x 0.73 in
• Display:
  5 inch IPS HD resolution 720 x 1280;
  LED backlight; Touch Screen: 5 points multi-touch
  capacitive panel with Dragontrail hardened glass
• Keys:
  Physical Keys: 2 side scan keys; Power On/Off; Volume Up/
  Down; 3 user programmable Android™ keys
• Weight(with battery):
  With Battery: 285.0 g / 10.0 oz

READING PERFORMANCE

• Camera:
  Resolution: 13 megapixel; Illumination: User controllable
  LED flash; Lens: Auto focus
• Scan Engine:
  2D Ultra slim area imager (supports 1D / 2D codes);
  Datalogic’s ‘Green Spot’ for good-read feedback;
  Halogen™ DE2102-HP:
  Depth of Field: 4 to 90 cm / 1.6 to 35 in, depending on bar
  code density and type; Resolution: Megapixel (1280 x 800
  pixels); Illumination: White and Red LEDs (for Digimarc);
  Aiming: 650nm VLD; Field of View: 42°H x 26°V
• Print contrast(Minimum):
  25%
• Minimum element width:
  Halogen™ DE2102-HP:
  1D Linear: 0.0635 mm / 2.5 mils; PDF: 0.0762 mm / 3 mils;
  Data Matrix: 0.152 mm / 6 mils

SAFETY & REGULATORY

• Agency Approvals:
  The product meets necessary safety and regulatory approvals for its intended use.
• Environmental Compliance:
  Complies to EU RoHS

SOFTWARE

• Applications:
  Datalogic’s SoftSpot technology for configurable soft triggers; Supports Datalogic’s Queue Busting app; Enterprise class PTT available from Zello
• Provisioning:
  Android Zero-Touch, QR Code enrollment, NFC Bump provisioning
• Configuration and maintenance
  Scan2Deploy Studio, OEMConfig
• Software Maintenance:
  Datalogic Shield: recurring security patches, firmware updates, and OS upgrades.
• Development:
  Java, Cordova and Xamarin SDK available
• MDM Compatibility:
  SOTI MobiControl, VMWare AirWatch, Wavelink Avalanche, 42Gears SureMDMSOTI MobiControl, VMWare AirWatch, Ivanti Avalanche, 42Gears SureMDM, Microsoft Intune
• Terminal Emulation Compatibility:
  StayLinked SmartTE, Ivanti Velocity

SYSTEM

• Expansion slots:
  Micro-SD card slot: Compatible with Micro SD-HC cards;
  Data transfer up to 48 Mbps; User-accessible
• SIM Slot:
  MicroSIM Standard size
• Memory:
  System RAM: 4 GB; eMMC Flash: 32 GB
• Microprocessor:
  2 GHz Octa-core
• Operating system:
  Android v11 with GMS / AER (Upgradeable to Android 13+)
• Real-Time Clock:
  Time and date stamping under software control

WARRANTY

1-Year Factory Warranty
