Name: Datalogic Magellan 3510HSi 2D POS Horizontal In-Counter Barcode Scanner - DCI Scanning
Availability: InStock

The Magellan 3510HSi series of scanners continue the Datalogic tradition of high performance imaging for the point-of-sale. With the same cables, mounts and exterior plastics as the Magellan 3550HSi, the 3510HSi scanner is easy to integrate into existing installations.

DATALOGIC MAGELLAN 3510HSI POS HORIZONTAL BARCODE SCANNER DATASHEET

Description

FEATURED

Advanced digital imaging provides class-leading performance and reliability
Seamless 1D, 2D and Digimarc® digital watermark reading
Smoothly reads all bar codes, whether displayed on cell phones or printed
Subtle, adaptive illumination for user comfort
Solid-state electronics for silent operation and superior reliability
Powers from single Type A USB port- 2.5W, available Magellan Customer Service
Scanner (CSS) with omni-mount for reading cell phones, coupons and loyalty cards
Software driven – flexible and upgradeable
Image capture
Micro SD card slot
Multiple interfaces in every unit
Powered USB auxiliary port – Not enabled when connected to 5V USB Type A host port
Checkpoint Systems and Tyco Sensormatic EAS compatible
Diagnostics reporting
EASEOFCARE Service Plans offer a wide range of service options to protect your
investment, ensuring maximum productivity and ROI

Summary

IN-COUNTER HIGH PERFORMANCE BAR CODE READER

The Magellan 3510HSi series of scanners continue the Datalogic tradition of high performance imaging for the point-of-sale. With the same cables, mounts and exterior plastics as the Magellan 3550HSi, the 3510HSi scanner is easy to integrate into existing installations. The new electronics platform allows the M3510HSi to power from a single 5V USB connection, providing outstanding performance and easy connection to any POS system.

With a large field-of-view and the capabilities of imaging, the 3510HSi scanners provide outstanding performance on hard-to-read bar codes and seamless reading of a wide variety of bar codes. This Magellan scanner enables both high speed sweep and presentation scanning techniques ensuring maximum productivity and ergonomic ease, even with truncated (shortened), out-of-spec or poorly printed codes.

ENHANCING THE CUSTOMER EXPERIENCE

The optional Magellan Customer Service Scanner (CSS) enables retailers to easily engage their customers in mobile commerce programs, allowing them to scan bar codes from mobile phone screens or paper coupons while the cashier continues to scan regular items in parallel, resulting in a significant reduction in total transaction time.

ENTERPRISE FEATURES

Remote management is supported for OPOS, JavaPOS, Toshiba Remote Management with IBM Systems Director® and Wavelink® Avalanche®. Additional capabilities are available with the Value Added Features included in every Magellan scanner.

SUITABLE APPLICATIONS

Retail: Point of Sale, Mobile Marketing
Capabilities, Age Verification, 2D Bar
Codes

Specifications

DECODING CAPABILITY

1D / Linear Codes:
Autodiscriminates all standard 1D codes including GS1
DataBar™ linear codes.
2D Codes:
Aztec Code; Data Matrix (ECC200 only); QR Code
Stacked Codes:
GS1 DataBar Composites; GS1 DataBar Expanded
Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked
Omnidirectional; MicroPDF417; PDF417
Digital Watermarks:
Optional support for Digimarc® Barcodes/GS1 DW Code

ELECTRICAL

Power Requirements:
AC Input: 100-240 VAC, 50-60 Hz
DC Input: 5-12V
Power Consumption:
Maximum: 2.25W @ 5V; 3.3W @ 12V
Typical (RMS): 1.6W @ 5V; 2.1W @ 12V
Sleep Mode (RMS): 0.95W @ 5V; 1.25W @ 12V

ENVIRONMENTAL

Ambient Light:
0 to 86,100 lux
ESD Protection(Air Discharge):
25 kV
Humidity (Non-Condensing):
5 – 95%
Particulate and Water Sealing:
IP52
Temperature:
Operating: 10 to 40 °C / 50 to 104 °F
Storage/Transport: -40 to 70 °C / -40 to 158 °F

INTERFACES

Interfaces:
OEM (IBM) USB; RS-232; USB Keyboard, USB Com, USB
TEC
Auxiliary Ports:
Powered Type A USB (USB Com) Requires power supply
or 12V Host power

OPTIONAL FEATURES

EAS Features:
Checkpoint Systems: Integrated EAS hardware will work
with Counterpoint IX and Evolve D11 models;
Sensormatic: Good Read Acknowledgement
Value Added Features:
Diagnostic Reporting; Host Download;
Magellan ULE Scripting

PHYSICAL CHARACTERISTICS

Dimensions:
Magellan Model 3510HSi:
Depth (Below Counter): 8.7 cm / 3.4 in
Length: 15.2 cm / 6.0 in
Width: 15.2 cm / 6.0 in
Weight:
0.98 kg / 2.16 lb

READING PERFORMANCE

Image Capture:
Graphic Formats: BMP, JPEG
Image Sensor:
1 MP; 1280 x 800 pixels; Graphic Formats: JPEG, BMP
Light Source:
Multiple diffused LEDs, orientation and wavelength
optimized for eye comfort
Print Contrast Ratio(Minimum):
25%
Read Height:
10.2 cm / 4.0 in
Read Rate(Maximum):
30 Million pixels per second
Reading Angle:
Pitch: +/- 65°; Roll (Tilt): 0 – 360°; Skew (Yaw): +/- 75°
Reading Indicators:
Audio beeper with adjustable tone and volume;
Good Read LED; Good Transmission
Resolution (Maximum):
5 mil

SAFETY & REGULATORY

Agency Approvals:
The product meets necessary safety and regulatory
approvals for its intended use.
The Quick Reference Guide for this product can be
referred to for a complete list of certifications.
Environmental Compliance:
Complies to China RoHS; Complies to EU RoHS
LED Classification:
EN62471 and IEC62471 Lamp Illumination – Exempt
Group

UTILITIES

Scanalyzer:
Magellan Scanalyzer configuration software is available
for download at www.datalogic.com.
OPOS / JavaPOS:
JavaPOS Utilities are available for download at no charge.
OPOS Utilities are available for download at no charge.
